240 Single Stage Compressor

Name: 240 Single Stage Compressor
Brand: REAL AIR TECHNOLOGIES PVT. LTD.
Price: 33500.00 INR
Availability: InStock

Price 33500.00 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

240 Single Stage Compressor Specification

Phase
Single Phase

Noise Level
78 dB

Motor Power
3 HP

Frequency
50 Hz

Filtration Grade
Industrial

Weight
110 kg

Power Rating
2.2 kW

Flow Rate
240 LPM

Drive Type
Belt Drive

Control System
Automatic Start/Stop

Pressure Capacity
8 Bar

Cooling Method
Air Cooled

Usage
Industrial

Type Of Compressor
Single Stage Compressor

Allied Equipment
Pressure Gauge, Safety Valve, Drain Valve

Configuration
Portable

Power Source
Electric

Silent
No

Lubrication Type
Oil Lubricated

Voltage
230 Volt (v)

Driven Mode
Belt Driven

Warranty
1 Year

Air Tank Capacity
160 Litres

No Of Cylinders
2

Max Speed
1000 RPM

Application
Workshop, Garage, Small Industries

Discharge Outlet Size
1/2 Inch

Piston Type
Aluminium Alloy

Dimensions (LxWxH)
1100 x 450 x 850 mm

Cylinder Material
Cast Iron

Mounting Type
Base Mounted

240 Single Stage Compressor Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA)

Delivery Time
1 Week

Main Domestic Market
All India

About 240 Single Stage Compressor

Are you looking for an air compressor of good quality? If yes, then it is the right time to invest in our offered 240 Single Stage Compressor of unmatched quality. Since it is made of class-A material and using the technologically advanced tools, it absolutely complies with the industrial quality standards. Apart from nonpareil quality, it is the affordability and efficient performance of our 240 Single Stage Compressor that makes it one of the best product to buy.

Product Details:

Minimum Order Quantity	1 Unit
Number Of Cylinder	2
Horse Power	2 HP
Brand	Real
Compressor Technology	Reciprocating Compressor
Model Name/Number	240
Maximum Flow Rate (CFM)	14.85
Discharge Pressure	80 psig
Air Tank Capacity	150 Ltr.
Air Quality Standard	Class II
Number Of Compression Stages	Single Stage
Lubrication Style	Splash Lubrication
Cooling Method	Air Cooled
Compressor Noise Level (Db)	72
Rental Available	No
Spares Available	Yes
Is It Portable	Yes
Installation/After Sales Service Available	Yes
Warranty	1 Year
Motor	Single phase 230 volt 50 Hz
Filter Type	Round shape with imported paper media
Motor Speed	1440
Automation Grade	Semi auto
Weight	160 kg
Tank Thickness	4 mm
Frequency	50 hz
Number Of Cylinders	2
Phase	Single Phase
Cylinder Type	Cast iron with flange mount
Voltage	230 v
Material	Cast iron
Accessories	pressure gauge,pressure cut off switch,safety valve,drain valve,delivery valve,air filter
Operational Display Type	NA
Power Source	AC Single Phase
Maximum Flow Rate	0-20 cfm
Piston Displacement	14.85 cfm/ 420 Ltr/min

Robust Build and Reliable Performance

Manufactured for longevity and stability, this compressor features a cast iron cylinder and aluminium alloy piston, ensuring resistance against wear and high thermal efficiency. Its belt-driven, oil-lubricated mechanism delivers smooth operation suitable for both periodic and extended use in demanding work environments.

Ease of Use and Portability

With a base-mounted, portable configuration and manageable dimensions (1100 x 450 x 850 mm), this unit is easy to move and install in confined workshop or garage spaces. Automatic start/stop and a clear control system streamline daily operations for users.

Comprehensive Safety and Control

Equipped with essential safety features such as a pressure gauge, safety valve, and drain valve, this compressor safeguards both users and equipment. The automatic control system ensures reliable pressure management and smooth transitions during operation.

FAQ's of 240 Single Stage Compressor:

Q: How do I install the 240 Single Stage Compressor at my location?

A: Installation is straightforward due to its base-mounted, portable design. Place the compressor on a level surface near a 230V power outlet and connect the required accessories. Ensure the workspace allows access to the controls and air outlet for efficient and safe use.

Q: What is the main benefit of the cast iron cylinder and aluminium alloy piston?

A: The combination of a cast iron cylinder and aluminium alloy piston maximizes durability and heat dissipation, ensuring longer service life, consistent performance, and reduced maintenance in industrial environments.

Q: When should I perform maintenance on this oil-lubricated compressor?

A: Routine maintenance includes checking and replacing the lubricant as per the manufacturer's guidelines, usually every 3 to 6 months or after heavy use, and regular inspection of safety valves and pressure gauges to guarantee safe operation.

Q: Where can this compressor be effectively used?

A: This compressor is ideal for workshops, garages, and small-scale industries where portable, efficient compressed air is essential for a variety of industrial and maintenance tasks.

Q: What is the process for draining the air tank and ensuring safe operation?

A: After use, release the built-up air via the 1/2 inch discharge outlet and open the drain valve to remove accumulated condensate. Periodic draining prevents moisture buildup, extending the compressor's lifespan and maintaining safe performance.

Q: How does the automatic start/stop control benefit users?

A: The automatic start/stop control system regulates pressure efficiently, starting the compressor when additional air is required and stopping it once the desired capacity is reached. This minimizes energy consumption and enhances operational safety.
